Reynolds Apparatus



<< Previous   Reynolds Apparatus   Next >>
Product Specification

Closed Circuit Test Rig: Reynolds apparatus for demonstration of streamlined and turbulent flow



a) Apparatus consists of an M.S. supply tank of size 30 liters. Fitted with suitable flow damping sieves.  A transparent tube of about 1.0m lengths is attached to an elliptical inlet and is provided with a control valve to obtain the required flow rate in the tube. A small can with suitable needle and valve is provided for injecting dye in the transparent tube for flow visualisation.  A stopwatch and an M.S. collecting tank of size 35 liters. With gauge glass scale fitting, a drain valve, a bend are provided to measure the flow rate.
b)  A 220 volt AC, 0.5 HP, single phase monoblock ISI pumpset with suitable pipe fittings, strainer foot valve, and a switch is provided to supply water to the test rig.
c)  A sump tank of size 200 liters with suitable drain is provided to store the water.  A strong iron stand fitted with wheels supports the complete test rig.  The unit is moveable.
All tanks are provided with FRP lining for total rust protection

Product Code : FM - 14
