Product Description

Flow Measurement (316)

The set up is designed to study following different type of units used for flow measurement.

Venturimeter
Orifice meter
Pitot tube
Rotameter
Water meter

Setup consists of flow measurement units under study, supply tank, Submersible pump for closed loop water circulation, acrylic measuring tank with graduated scale and differential pressure measuring arrangement mounted on stand alone structure.

Specification :

Product	Flow Measurement
Product code	316
Venturimeter	Size 18.5 mm, Bore 10 mm, Acrylic
Orifice meter	Size 18.5 mm, Bore 12 mm, Acrylic
Pitot tube	Size 18.5 mm, Acrylic
Rotameter	60-600 LPH
Water meter	Size ½"BSP, brass, Least count 1 lit
Supply tank	SS304
Measuring Tank	Capacity 3 lit, Acrylic
Pressure difference	Tube with graduated scale
Pump	Fractional horse power, type submersible
piping	3/4/' BSP, CPVC
Overall dimensions	550Wx475Dx750H mm

Utilities Required :

Electric supply	230 4/- 10 VAC, 50 Hz, 1 phase
Water supply	Distilled water @10 liters
