Cascade Control Trainer

Cascade Control Trainer

Product Details:


Product Description

Driven by technical excellence, we are counted as the topmost manufacturer and supplier of excellent quality Cascade Control Trainer. This is designed to understand the advanced control methods used for complex processes in the industries. It consists of water supply tank, pump, level transmitter, transparent level tank, orifice meters with differential pressure transmitters, rotameters, pneumatic control valve, I/P converter and serial based dual loop controller. To meet the variegated needs of our valuable customers, we offer this Cascade Control Trainer in various models at reasonable prices.


  • Provides accuracy in result
  • Longer service life
  • Energy efficient

Specifications :


Cascade control trainer

Product code


Control unit

ADAM-4022T Serial based dual loop PID controller; Analog input 4, Analog output 2, Digital input 2, Digital output 2. with RS485 communication.


USB port using RS485-USB converter

DP transmitter

Type Capacitance, two wire, Range 0-200 mm, Output 4-20 mA sq.root

Level transmitter

Type Electronic, two wire, Range 0-250 mm, Output 4-20mA

l/p converter

Input 4-20mA, Output 3-15 psig

Control valve

Type Pneumatic, Size 1/4", Input 3-15 psig, Air to close, Char. Linear


10-100 LPH


Fractional horse power, type submersible

Process tank

Transparent, Acrylic, with 0-100% graduated scale

Supply tank


Flow measurement

Orifice meter

Air filter regulator

Range 0-2.5 kg/cm2

Pressure gauge

Range 0-2.5 kg/cm2(1No), Range 0-7 kg/cm2(1No)

Overall dimensions

550Wx475Dx520H mm


SCADA software package; Mini Compressor

Utilities Required

Electric supply

Air Supply

230 +/- 10 VAC, 50 Hz, 1 phase

Clean, oil and moisture free air,

Water supply

Pressure 2 Bar, Air consumption 50 LPH

Distilled water liters

Support table


Size: 800Wx800Dx750H in mm

IBM compatible with standard Configuration
