Air-Handling Unit Experimental Setup With Lab

Air-Handling Unit Experimental Setup With Lab

Product Details:


Product Description

Air-Handling Unit Experimental Set up With Lab

Experimntal Contents
  • Study for the principle of air-conditioning in construct field.
  • Experiment cooling and heating with control of intake, exhaust and return air.
  • Measurement performance of individual device in mechanical air-conditioning.
  • Control Air-conditioning with electric penal or computing programming software.
  • Measurement performance of refrigeration system.
  • Obtaining data and control the system with NI DAQ equipment.
  • Experiment with computing programming of NI LabView.
  • Drawing psychrometric chart and analysis with real time.
Main elements specification
  • NI DAQ IAir-Handling Unit Experimental Set up With Lab, Air-Handling Unit Experimental,nstruments
  • NI cDAQ 9172 Chassis (8 Modules)
  • NI 9205 32-Ch +200 mV to +10 V, 16-Bit, 250 kS/s Analog Input Module
  • NI 9211 4-Channel, 14 S/s, 24-Bit, +80 mV Thermocouple Input Module
Refrigerator, heater, thermostat and sensors
  • Refrigerator : Single AC 220V, 1.5HP
  • Heater : Heater AC 220V, 3kW
  • Thermostat : For water, Magnet pump
  • Sensor : Relative humidity, Temperature, Differential pressure
Power and Size
  • Single, AC 220V, 30A
  • SIZE(mm): 2600(W) x 710(D) x 1660(H)
